Front Mount Male & Female 7/8′ ′ 2, 3, 4, 5, 6, 8 PCB Panel Connector

Front Mount Male & Female 7/8′ ′ 2, 3, 4, 5, 6, 8 PCB Panel Connector

INQUIRY

Basic Info.

Certification

RoHS, CE, ISO9001

Application

UHF, FPC, Microwave, Automobile, Energy

Contact Resistance

<=8m Omega;

Contact Material

Copper Alloy

Surface Treatment

Nickel Plating

Housing

Copper Alloy

Temperature Range

-20~+85 Degree

IP Rating

IP67

Connector Series

7/8′

Mounting Type

Straight

Shielding

Available

Coupling Nut/Screw

Brass with Nickel Plated

3/4/5/6/8 Pin

Locking Type

Fix Screw

Transport Package

PE Bag/Carton or According Customize Packing

Trademark

Co-Fly

Origin

Shanghai, China

HS Code

853690

Packaging & Delivery

Package Size

40.00cm * 25.00cm * 25.00cm

Package Gross Weight

0.200kg

Product Description

Front Mount Male & Female 7/8'' 2, 3, 4, 5, 6, 8 PCB Panel Connector

Description of 7/8'' panel connector,IP67 7/8'' PCB connector ,fix thread 7/8''

Φ Panel field 7/8'' connector,fix screw with self-locking threaded joint,waterproof IP67 7/8'' cable connector.

Φ Can be easily connected to proximity switches,photoelectric barries,flow moitoring devices and field bus components sensor devices and actuator devices.

Φ Satisfy all the requirements of sensor devices and actuator devices in automation technology.

Technical data for Front Mount Male & Female 7/8'' 2, 3, 4, 5, 6, 8 PCB Panel Connector

Technical data of cable waterproof connector

Φ Standard :IEC 61076-2-101

Φ Coding : A,B,D

Φ Pins: 2~8 pin

Φ Ambient temperature:-20°C~+85°C

Φ Insulation resistance ≥ 1000M Ω

Φ Degree of peotection : IP67 in locked condition

Specification for Front Mount Male & Female 7/8'' 2, 3, 4, 5, 6, 8 PCB Panel Connector

Cable/Connector specification

Φ Insert : PA+GF

Φ Contact:Copper Alloy with gold plating

Φ Overmold:TPU

Φ Cable Jacket:PVC or PUR

Φ Wire insulation:PVC

Φ Cable length:Option

Front Mount Male & Female 7/8′ ′ 2, 3, 4, 5, 6, 8 PCB Panel Connector


1. Q: What is the necessary information needed for quotation?
   A:The series(M5/M8/M10/M12/M23),coding,male or female,pin number,cable length.

2. Q: What is the minimum order quantity(MOQ)?
   A:100 pcs or negotiatable.

3. Q: What do the certifications have?
   A: ISO9001:2008, ISO14001, CSA. IATF16949.

4. Q: What does Co-fly can provide for the product' certification?
   A: IP67, IP69, UL, CE and RoHS.

5. Q: Sample lead time?
   A: One week.

6. Q: Volume order lead time?
   A: 3-4 weeks.

7. Q: Do you provide inspection on the incoming materials before production and inspect the finished products shipment?
   A: Yes. We have Incoming material inspection, In process quality check and Outgoing goods quality check.

8. Q: How do you ship the finished product?
   A: Based on the customer request.

9. Q: What kind of delivery terms or trade terms is available?
   A: T/T, FOB ,EXW, FOB are all available.
